UP600+ Intelligent Charger System 110V.
UP600+ Balance Charger has dual charge management system designed for Align E1 Agricultural Helicopter, charging either two 6S Li-Po battery or Li-HV battery and storage battery in the meantime. Intelligent and easy to charge at one button.
|
Product Information Dual Battery Charging Support Charging Current Balance Charging and Store (Maintain) Mode Last Charging Settings Saved Multi Protection: Overload, Over-current, Reverse Polarity, Temperature |
Specifications UP600+ Balance Charger x 1 Balance Connector x 2 Charging Cable x 2 Power Cord x 1 Charging Ports: 2 Function: Charge Mode/Storage Mode Support Battery Type: LiPo / LiHV Battery Cell: 6S Battery (Charging 2S/3S battery independently) Balanced Current: 1.5A/cell Output Voltage: DC 7.4~25.2V Protection Functions :Overload Protection, Over-current Protection, Reverse Polarity, Temperature Protection Display: LED Indicator + LCD Intelligent Display |
NOTE:
1. Do not leave the charger is operating unattended as it may cause a fire.
2. If the battery becomes hot while high current discharging or flying, please do not charge the battery immediately. Wait to cool down(about 20 mins), then inspect to recharge. If against follow the original factory using rules, possibly cause the battery to inflate or any dangerous accident happens.
3. Before placing your order, please make sure to confirm local voltage for buying correct input voltage charger to prevent any unexpected danger and fire resulting from wrong voltage input.
4. Keep the charger and battery away from flammable items.
5. Never leave the charger unattended, in case of causing an accident.
6. The battery should be charged under 5-40 degree Celsius environment.
7. Keep the charger away from dust, moist, rain, heat, direct sunshine and vibration.
8. Before you power off the charger, please “stop” the charger first, unplug the battery, then unplug the power cord of the charger.
| Charger Specifications | |
| AC Input Voltage | 100~120V |
| Charge Power | 1200W (600W×2) |
| Charge Current | 5A/10A/15A/20A/25A |
| Discharge Power | 80W (40W×2) |
| Supported Battery Types | LiPo/LiHV |
| LiPo/LiIon/Life Cell Count | 1-6S Battery |
| Dimension | 268x140x127mm - 10.55x5.51x5in |
| Weight | 3.1kg - 6.83lb |
UP600+ Intelligent Charger System 110V
- Brand ALIGN
- Product Code: 01-HEC00008
- Availability: Out Of Stock
-
$389.00
