Product Information and estimated shipping date will be updated as information becomes available from Align.
|
Standard Equipment TN70 Kit Set x 1 690 Carbon Fiber Blades x 1 105 Carbon Fiber Tail Blades x 1 ALIGN 105 High Performance Pipe x 1 |
Equipment Required for Assembly Transmitter (6-channel or more, helicopter system) Receiver (6-channel or more) or Remote Receiver OS-105 or Other Similar Nitro Motor x 1 Flybarless System Recommend MICROBEAST² x 1 Engine Starter x 1 Fuel Pump x 1 Engine Fuel x 1 DS830M High Voltage Brushless Servo x 3 DS835M High Voltage Brushless Servo x 1 DS530 Digital Servo x 1 B6M 2 In 1 Voltage Regulator Combo x 1 Digital Pitch Gauge Multi-Function Tester 2S1P 7.4V Li-Po 1900~2600mAh Battery x 1 Misc. Building Equipment *All Items Are Subject To Change By Align |
| Standard Equipment | |
| Kit | TN70 Kit |
| Model | RH70N36XW |
| Main Blades | Align 690 |
| Tail Blades | Align 105 |
| Electronics Included | |
| Flybarless System | Recommend Microbeast (Sold Separately) |
| Flybarless Programming | Lights & Dials, or Studiox APP using Optional BXA76404 Bluetooth Device |
| Stabilization Level Mode | Optional Upgrade |
| Rescue Mode | Optional Upgrade |
| Receiver Supported | DSM2/DSMX/DMSS Satellite, Futaba S.Bus, SRXL, JR XBUS, SUMD, M-Link, BEASTX SRXL, JETI UDI, SPPM, Standard Receiver |
| Nitro Equipment | |
| Muffler | Align 105 High Performance Pipe |
| Fuel Tank | 650cc |
| Governor Sensor | Beastx Governor Sensor |
| Specification | |
| Assembly Required | Yes |
| Length | 1355mm |
| Height | 397mm |
| Width | 202mm |
| Main Blade Length | 680 - 700mm |
| Main Rotor Diameter | 1543mm |
| Tail Blade Length | 105 - 115mm |
| Tail Rotor Diameter | 279mm |
| Drive Gear Ratio | 7.43 : 1 : 4.23 |
| Weight (Without Battery) | 4110g |
