Product Information

For 550, 600, 650, 700, 760, 800 Class RC Helicopters, Airplane, Giant Scale

Recommended Use: RC Helicopter - Cyclic and Nitro Throttle

High Speed Response

Gears: Metal Alloy

Motor: Japanese Made Brushless

Specifications

• Dead Band: 0.001ms (Default)
• Control System: +Pulse Width Control
• Working Frequency: 1520μs / 333hz
• Operating Voltage: 6 ~ 8.4 Volts
• Operating Temperature Range: -10 to + 60 Degree C
• Operating Speed:
  • @6V: 0.13 sec/60° degrees at no load
  • @7.4V: 0.10 sec/60° degrees at no load
  • @8.4V: 0.09 sec/60° degrees at no load
• Stall Torque:
  • @6V: 169.4 oz-in (12.2 kg/cm)
  • @7.4V: 211 oz-in (15.2 kg/cm)
  • @8.4V: 231.9 oz-in (16.7 kg/cm)
• 360° Modifiable: NO
• Motor Type: Brushless Motor
• Potentiometer Drive: Indirect Drive
• Bearing Type: Dual Ball Bearings
• Gear Type: Metal Gears
• Connector Wire Length: 24.0 cm (9.4 in)
• Dimensions: 40x20x40mm
• Weight: 63g (2.22oz)
