Product Information

Ideal for 1/10 Surface Application

Combining full metal gears, case and amazing speed.

The low-profile dimensions makes it perfect for any vehicle that is
cramped for space.

CNC Machined Metal Case Design for Exceptional Cooling.

HD 4096 Resolution, 0.0008ms Dead Band.

Superior Holding Torque, Japanese Brushless Motor.

High speed, incredible efficiency, and low power consumption than
comparable servos.

Specifications

• Dead Band: 0.0008ms (Default)
• Spline Size: 6mm - 25T
• Control System: +Pulse Width Control
• Working Frequency: 1500μs / 333hz
• Operating Voltage: 3.5 ~ 7.4 Volts
• Operating Temperature Range: -10 to + 60 Degree C
• Operating Speed:
  • @4.8V: 0.10 sec/60° degrees at no load
  • @6.0V: 0.08 sec/60° degrees at no load
  • @7.4V: 0.07 sec/60° degrees at no load
• Stall Torque:
  • @4.8V: 138.9 oz-in (10 kg/cm)
  • @6.0V: 184.7 oz-in (13.3 kg/cm)
  • @7.4V: 233.3 oz-in (16.8 kg/cm)
• Motor Type: Japanese-made Brushless Motor
• Potentiometer Drive: Indirect Drive
• Driver Type: FET
• Bearing Type: 12x8 mm Double Bearings
• Gear Type: Chrome-Titanium Alloy Gear
• Dimensions: 40.5x20.5x23.1mm - 1.59x0.79x0.91in
• Weight: 53.51g (1.89 oz)
