ALIGN DS830M Digital Cyclic HV Servo
Supports both analog and digital control signals.
|
Product Information For T-REX TB60, TB70 TN70 Series Wire Length: 260mm Gears: All Metal Gear Material: Hardened High Strength Super Alloy Case: CNC Aluminum Resolution: Ultra High Signal Gear Replacement DS820 Servo Gear Set - HSP82001 Servo Composite Material Case Replacement DS820-825 Upper Lower Cover - HSP82002 |
Package Includes DS830M High Voltage Brushless Servo (260mm) x 1 Servo Arm x 1 DS615/655 Servo Arm Set x 1 DS615/655 Rubber Group x 1 (Square rubber x 4/washer x 4/screw x 1) Socket Button Head Screw x 4 (M2.5x10mm) |
| Servo Specs | |
| Cyclic Servo | YES |
| RC Use | YES |
| Wire Length | 260mm |
| Case | All Metal |
| Gear Set | Metal |
| Voltage Range | 7.4-8.4V DC |
| Stall Torque | 22kg.cm (7.4V) - 23kg.cm (8.4V) |
| Motion Speed | 0.06sec/60° (7.4V) - 0.055sec/60° (8.4V) |
| Tempeature Range | -20°C ~ +60°C |
| Swashplate Frequency | 200Hz |
| Pulse Length | 1520µs |
| Dimension | 40 x 20 x 39mm |
| Weight | 80g |
DS830M High Voltage Brushless Servo - Cyclic (260mm)
- Brand ALIGN
- Product Code: 01-HSD83002
- Availability: Out Of Stock
-
$189.99
